1. Detector type: uncooled vanadium oxide 2. Detector resolution 640×512 3. Infrared response band: center wavelength 10.55μm 4. Detectable gases: sulfur hexafluoride, ammonia, ethylene, vinyl
ether, vinyl chloride, trichloroethylene, methyl vinyl ketone,
propylene, acrolein, acrylonitrile, ethyl cyanoacrylate, allyl
fluoride, allyl chloride, allyl bromide, furan 5. Pixel size: 12μm 6. Thermal sensitivity: 23mk@7-14um 7. Frame rate: 25Hz 8. Focal length: 19mm 9. Field of view Angle: 23°x18° 10. Focus mode: Manual focus 11. Temperature measurement range: '-20 ℃ -120 ℃ 12. Temperature measurement accuracy: ±2% or ±2℃ 13. Temperature resolution: 0.1°C 14. Temperature measurement mode: central point/cold hot spot
tracking and temperature display 15. Custom point, line, area temperature measurement: movable
point/line/area temperature measurement; Supports a maximum of 10
points, 10 areas, and 10 lines 16. Temperature measurement unit: Celsius, Fahrenheit, Kelvin 17. Emissivity setting: 0.01-1.00, step size 0.01 18. The ambient temperature is set to -10~50℃, and the step length
is 1℃ 19. Distance setting: 1-20m, step length 1m 20. Image mode: infrared, visible light, dual light fusion, picture
in picture, detail enhancement 21. Temperature alarm: Yes 22. Temperature wide stretching: manual/automatic temperature range 23. Laser pointer: Yes 24. Visible phase: 500w pixels 25. Video and photo storage: XX-IR.jpg (infrared pictures with
temperature data) and XX-DC.jpg (pure visible light pictures);
Video without data 26. Display size: 3.5-inch touch screen (480x640) 27. Image naming: automatic/manual input naming, scan QR code
naming 28. Memory card: Standard 32GB MicroSD card, maximum 512GB storage 29. Battery type: Rechargeable lithium battery, removable 30. Power interface: USB TypeC 31. Connection mode: USB, SD card, WiFi (AP mode or networking
mode) 32. Charging time: about 3h 33. Working hours: about 3h 34. Cloud function: It can transmit shooting data to the cloud disk
for multi-client sharing and secondary analysis; Supports automatic
time synchronization 35. Power management: Automatic shutdown: 5 minutes, 10 minutes, 20
minutes, no automatic shutdown 36. Analysis software: PC&APP 37. Tripod support: Yes 38. Operating temperature: -10 to +50°C 39. Storage temperature: -20 to +60°C 40. Relative humidity: 10% to 95%, non-condensing 41. Dimensions (H x W x D) : 256.4 x 105.1 x 105.3mm 42. Weight: About 670g |
